Shaanxi Jinshenghong Cable Co., Ltd. is one of the most reliable manufacturers and suppliers of submersible water pump cable丨manufacturer in china in China. Please feel free to wholesale high quality customized products at low price from our factory. For free sample and cheap products, contact us now.
Products applitation
-Rated voltage: generally 450/750V
-Conductor DC resistance: At 20 ℃, there are clear regulations on the DC resistance of cable conductors with different cross-sections. For example, for a 1.5mm ² copper core cable, the DC resistance should not exceed 12.1 Ω/km; for a 4mm ² copper core cable, the DC resistance should not exceed 4.95 Ω/km.
-Insulation resistance: After immersion and withstand voltage, the insulation resistance should not be less than 100M Ω/km at 20 ℃.
-Power frequency withstand voltage: After immersing the insulated wire core in room temperature water for 6 hours, it can withstand a voltage of 2500V without breakdown after being pressurized for 5 minutes; After being immersed in room temperature water for 6 hours, the finished cable can withstand a voltage of 2500V without breakdown after being pressurized for 15 minutes.
SPECIFICATION
-Working temperature: The allowable working temperature for cable cores is generally 65 ℃, and higher temperatures can be reached for special requirements.
-Waterproof performance: It has good electrical insulation performance under immersion and high water pressure, and the sheath material has a small water absorption under water pressure.
-Bending performance: Good bending performance, soft, and able to withstand frequent movement.
Characteristic
Physical performance parameters
-Core material: made of oxygen free copper
-Sheath material: rubber
-Cable outer diameter: Different specifications of cables have different outer diameters. For example, a 3-core 1.5mm ² submersible pump cable has a maximum outer diameter of about 17.0mm; a 3-core 4mm ²
cable has a maximum outer diameter of about 18.0mm.
Production and packaging
product key technologies
Shaanxi J.S.H Cable Co., Ltd. has become acomprehensive enterpriseintegrating 're.search and development',*production'sales' and "after-sales'.The companycovers an area of more than 90 acres, withmore than 200 employees.Including engineers, R&D team, professional and technicalpersonnel and other diversified talents, canproduce 5 categories, more than 500 typesmore than 16,000 specifications of wire andcable. Such as cross-linked power cablesmedium-voltage/high-voltage power cablesPVC power cables, branch cables, controlcables, coal mine fire-retardant cables.fire-retardantfire-resistant cables low-smokelow-halogen cables, low-smoke halogen-freecables,aerial cables,rubber-sheathed cables.PVC wires, steel-core aluminium strandedwires and so on.
PACKAGING
1.Packing type:Carton and wooden case,also be packged according to customer requirements
2.Modes of transportation:by sea,by air or land transportaion,of course,a small amount can also by Express
TRASPORTATION mODE AND CERTIFICATE
Discover the seamless world of freight logistics with Shaanxi J.S.H Cable Co., Ltd. Our global logistics network, as shown on the map, connects every corner of the world, ensuring your products reach their destination efficiently. Whether it's by air, land, or sea, we offer diverse transportation solutions, represented by our dedicated air freight, truck transportation, and ocean freight services. Witness the entire process from manufacturing in our well - stocked factory, to the precision of product packaging, and finally to the safe delivery of your cables. Trust us to handle your logistics needs with expertise and care. 🚚✈️🚢"
1. Shaanxi J.S.H Cable Co., Ltd. – Certified for Excellence! Our certificates prove we meet global standards, so you get reliable, high - quality cables every time.
2. Trust Shaanxi J.S.H Cable Co., Ltd. – Certified Quality! These credentials back our commitment to top - notch cables that meet international norms.
3. Shaanxi J.S.H Cable Co., Ltd.: Certified, Reliable, Trusted. Our certificates ensure our cables deliver the quality and performance you need.
WHY CHOOSE US
OUR ADVANTAGES
1.20 years production experience.
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3. OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7.Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.
